Images are representations only.
Price
Request a Quote
Stock
Out of Stock
- Size - 4-1/2"
- Type - 1125
- System (Tube & Socket) - Grade A Phosphor Bronze Tube with Bronze Socket
- Case Design - Open Front
- Process Connection Size - 1/4" Male NPT
- Connection Location - Lower
- Unit of Measure - Single Scale (PSI)
- Pressure Range - 0 to 10 psi
Description
- Size - 4-1/2"
- Type - 1125
- System (Tube & Socket) - Grade A Phosphor Bronze Tube with Bronze Socket
- Case Design - Open Front
- Process Connection Size - 1/4" Male NPT
- Connection Location - Lower
- Unit of Measure - Single Scale (PSI)
- Pressure Range - 0 to 10 psi
Product Series Specifications
Specifications
Brand
Accuracy
- ± 2-1-2 % ASME B40.100 Grade A
Applications
- Chemical & Petrochemical
- Filter, Level & Flow Measurement
- Mining & Metals
- Refineries
- Water & Wastewater Pressure Control
Enclosure Finish
- Case: Black Epoxy Coated
Enclosure, Body Material
- Cast Aluminum, Black Epoxy Coated
Lens
- Window: Glass Lens
Materials of Construction
- Bourdon Tube: Grade A Phosphor Bronze
- Dial: White Painted Aluminum with Black Markings
- Socket: Bronze
Mounting
- Stem
- Surface Mount
Movement
- Bronze
NPT Connection
- 1/2” NPT Female
- 1/4” NPT Male
Pressure Range
- bar: 0.69 to 68.95
- kPa: 68.95 to 6,895
- psi: 10 to 1,000
Pressure Type
- Differential
Ring Material
- Aluminum, Black Epoxy Coated
Size
- Dial: 4.5”
- Dial: 6” (152.4 mm)
Product Series Documentation
Documentation
Product Manuals
Installation & Maintenance
Product Information
- Ammonia Applications (pdf) (294 KB)
- High Pressure Tubing Connection (pdf) (664 KB)
- Hysteresis Error for 316 Stainless Steel Bourbon Tubes (pdf) (663 KB)
- Rupture, Proof and Overpressure of Ashcroft Bourdon Tubes (pdf) (479 KB)
- Safety Concerns Using Repaired and Reconditioned Pressure Gauges (pdf) (665 KB)
- Storage and Shelf Life of Gauges (pdf) (668 KB)
- Stress Corrosion Cracking Resistance of K500 Monel vs Monel 400 in Hydrofluoric Acid (pdf) (681 KB)
- Throttle Screw Selection Pressure Gauges (pdf) (454 KB)
